1 BBL | Uni-tank Fermenter | Single Wall

SKU FV-SW-BBL-001-STD
Shape
  • Details
  • Specifications
  • Downloads
  •   · greater than 25% headspace
      · cylindro-conical design
      · slotted, rotary spray-ball CIP w/ 360° coverage
      · CO2 blow-off arm
      · hop dosing port, w/ easy-access ladder hooks
      · rotating racking arm, w/ DIN fitting & easy-grip handle
      · ½” NPT sanitary thermowell
      · optional spring-loaded RTD
      · sample port with perlik style valve
      · pressure / vacuum relief valve ("PRV")
      · all butterfly valves included

  •   · 15 psi operating pressure uni-tank, tested to 30 psi
      · AISI 304 stainless steel, TIG weld construction
      · 11-gauge interior / 14-gauge cladding or equivalent
      · 3A standard 32 μin Ra (0.8 μm Ra) finish
      · reinforced stainless steel legs, w/ leveling foot pads
      · pressure-rated shadowless manway

  • Download Planning Dimensions
